Wired Pir Motion Sensor Dual Passive Infrared Detector

Note: Do Not Mount The Unit In Direct Sunlight Or Near Heat Sources.
Overview:
This Product Is A Wired Dual Passive Infrared Detector Exquisite Design Easy Installation. Fit For The Locations Of The Balcony Window Door Corridors Outdoor Etc. Imported High-End Infrared Sensor Smt Chip Technology Anti-Emi Anti-Rfi Design Temperature Compensation Pulse Count Led Switch Etc. Selectable Functions Can Be Integrated With Wired Alarm Host.

Features:
*Mcu Technology To Prevent All Kinds Of False Alarms.
*Smt Chip Anti-Emi Anti-Rfi Design. Anti-Tamper Alarm Function To Enhance Anti-Damage.
*The Pir Sensor Is A Wide Angle 15Mx15m With High Catch Performance And False Alarm Immunity.
*Automatic Temperature Compensation Adjustable Pulse Count.
*Led On/Off Optional Better Concealment.

Specifications:
Working Voltage: 9V-16V
Standby Current: 12Ma
Working Current: 18Ma
Wide Detector Angle: 85 (15Mx15m)
Detection Distance: 15M (No Barrier 25)
Detection Method: Low Noise Dual Element Pyroelectric Sensor
Tamper Switch: 12V 50Ma
Detection Speed: 0.3-3M/S
Sensitivity: Level 2 Adjustable
Led Color: Red
Installation Way: Wall/Ceiling Hanging
Installation Height: 2M-4M Adjustable
Casing Material: Abs
Operating Temperature: -10C To 50CBr>Item Size: Approx. 11.6 * 6.8 * 5Cm
Item Weight: Approx. 90G / 3.2Oz

Package Information:
Package Size: Approach. 16.3*7*5.5Cm/ 6.42*2.76*2.16In
Package Weight: Approach. 144G / 5.1OzBr>
You Will Receive
1 * Wired Pir Motion Sensor
2 * Mounting Bracket
1 * Accessory Bag
1 * User Manual
